Advantages:

• Power range with 4 sizes from 9 to 16 kW for renovation and new buildings
• Natural refrigerant R290
• Low refrigerant quantity (1.2 kg)
• High energy efficiency (SCOP >5 / A+++)
• Intelligent design for less maintenance and installation effort
• Flexible connection options (pipe routing to the rear, optionally downwards)
• One of the quietest models on the market
• Maximum flow temperature up to 75 °C
• Operating range down to –28 °C
• Optimized defrosting with different defrost modes
• Integrated communication interfaces (RS485 and Modbus)

Specifications HM093HFX:

• Rated power:
Heating (air 7 °C, water 35 °C): 9.00 kW
Heating (air 7 °C, water 55 °C): 9.00 kW
Heating (air 2 °C, water 35 °C): 9.00 kW
Cooling (air 35 °C, water 18 °C): 9.00 kW
Cooling (air 35 °C, water 7 °C): 9.00 kW
• COP:
Heating (air 7 °C, water 35 °C): 4.90
Heating (air 7 °C, water 55 °C): 3.20
Heating (air 2 °C, water 35 °C): 3.88
• EER:
Cooling (air 35 °C, water 18 °C): 3.90
Cooling (air 35 °C, water 7 °C): 3.24
• Operating range (flow temperature):
Heating Min. - Max.: 15 - 75 °C
Cooling Min. - Max.: 5 - 27 °C
Hot water min. - max.: 25 - 65 °C
• Operating range (outside temperature):
Heating Min. - Max.: -28 - 35
Cooling Min. - Max.: 5 - 48
• Refrigerant: R290, GWP=3
Pre-filled quantity: 1.2 kg
• Sound pressure level (at 5 m) heating:
Nominal value: 27 dB(A)
Silent mode: 26 dB(A)
• Dimensions (W x H x D): 520 x 1019 x 1560 mm (181 kg)
• Voltage, phase, frequency: 400 V / 3 Ph. / 50 Hz.

Indoor unit HN1639HC.NK0:

• Operating range (flow temperature):
Heating: 15 - 75 °C
Cooling: 5 - 27°C
Hot water: 15 - 80 °C
• Expansion tank | Capacity: 8 l
• Additional heating (electric):
Power per stage: 3 kW
Power supply: 400 V / 3 Ph. / 50 Hz
• Sound power level heating: 39 dB(A)
• Dimensions (W x H x D): 490 x 850 x 315 mm (31 kg)

BEFORE PURCHASE, PLEASE CONTACT US BY PHONE TO CONFIRM AVAILABILITY.
